sales of "Non-metallic 2000/3000 core SWR /WTC Lineup" begins

株式会社フジクラ(取締役社長CEO:岡田直樹)は、金属を使わないノンメタリック仕様の国内向け光ファイバケーブルのラインナップに、「2000心および3000心SWR®※1/WTC®※2」を新たに加え、販売を開始しました。
新製品「ノンメタリック2000心および3000心SWR®/WTC®」は、多心一括融着接続が可能な8心光ファイバリボンSWR®を当社独自技術のWTC®に実装したノンメタリック仕様の光ファイバケーブルです。
日本国内では、光ファイバケーブルを地下に布設する際、埋設管路の内径の制限により、光ファイバケーブル外径を24mm以下に抑える必要があります。
従来の被覆径250μmを使用したSWR®/WTC®では、ケーブル外径の制限により最大2000心が上限でしたが、被覆径200μmを使用したSWR®/WTC®では、3000心タイプの外径を23mmに抑え、地下管路への布設を可能としました。また、2000心タイプの外径も20mmとなり、さらなる細径高密度化を実現しています。
さらに、ノンメタリック構造であるため電磁誘導対策が不要となり、施工簡略化に効果を発揮するほか、難燃シース被覆の採用により建屋の内外を問わず布設できる特長を有しています。
また、実装する被覆径200μm SWR®の光ファイバ配列ピッチを250μmとしたことで、汎用光ファイバリボンとの融着接続を可能にしています。
現在、クラウドサービスや生成 AIの急速な普及・拡大により、通信トラフィックは加速度的に増加しています。フジクラは既存インフラ網を効率的に活用できる細径高密度のSWR®/ WTC®の供給により、高度な通信ネットワークの構築に寄与すると同時に、引き続き高品質かつ革新的な技術と製品開発によって、さらなる高度情報化社会の実現に貢献していきます。

Coating diameter 200μm 8-fiber SWR ®
Optical Fiber pitch

Non-metallic WTC ®

Structure of the new product "Non-metallic 2000-fiber and 3000-fiber SWR ® /WTC ®"

Traditional metallic
2000-core cable

New non-metallic
2000-core cable

New non-metallic
3000-core cable

Cross-sectional structure of the new product "Non-metallic 2000-fiber and 3000-fiber SWR ® /WTC ®"



Specifications for "Non-metallic 2000-fiber and 3000-fiber SWR ® /WTC ®"

Existing product (metallic finish) Newly released product (non-metallic finish)
Number of cores 2000 Hearts 2000 Hearts 3000 Hearts
Optical Fiber Diameter 250μm 200μm 200μm
Optical Fiber pitch 250μm 250μm 250μm
Standard Cable Outer Diameter 23mm 20mm 23mm

Product website:
Thin, high-density, flame-retardant, non-metallic Fiber Optic Cable

*1 SWR ® (Spider Web Ribbon ®)
Optical Fiber ribbon developed using Fujikura's proprietary technology. It is made by intermittently bonding Optical Fiber and is strong point / feature by its flexibility. It enables high-density mounting within Fiber Optic Cable, contributing to the creation of thinner, higher-density Fiber Optic Cable.

*2 WTC ® (Wrapping Tube Cable ®)
The name of a small-diameter, high-density Fiber Optic Cable that incorporates SWR® and was developed using Fujikura's proprietary technology. Fiber Optic Cable with a simple structure in which an Optical Fiber fiber ribbon is covered with a pressure-wrapped tape. Since it has a smaller diameter and higher density structure than conventional Fiber Optic Cable, such as the slot structure that is mainly used in Japan and the loose tube structure that is common overseas, it can use existing conduits and significantly shorten construction time.

・SWR ® (Spider Web Ribbon ®) and WTC ® (Wrapping Tube Cable ®) are registered trademarks of Fujikura.
